How can you pair the TaoTronics Pulse X Speaker with a mobile device via Bluetooth? What do the LED colors mean? How to use the buttons?
 |
Manufacturer: TaoTronics
|
CAUTION: Electrical Device. Read the safety instructions!
Step 1
Ensure that the TaoTronics Pulse X (TT-SK10) speaker is turned on and the battery fully charged. Do not separate the two devices for more than 3 feet while pairing.
Step 2
Once switched on, the loudspeaker is automatically set to the pairing mode and can be paired with other Bluetooth enabled devices. The LED flashes rapidly blue.
Step 3
Turn on the Bluetooth mode on your mobile device. It will automatically search for other Bluetooth enabled devices nearby. Choose the “PULSE X” device from the list. Has the pairing been successful, the speaker’s LED will stay solid blue and you will hear an acoustic signal. – In case your mobile device requests a password, please try the combination “0000” or “8888“.
Step 4
In order to perform a “factory reset“, simply slide a little pin / needle into the side between the charging port and the AUX port. Do not forget to remove the TaoTronics Pulse X (TT-SK10) speaker from your Bluetooth device list on your mobile device.
Additional Information
In case the speaker is connected to a device via the AUX cable, the Bluetooth function is turned off.
The following functions can be controlled via the different buttons.
| Function | Button How To / Control |
| Power On | Press and hold the power button for approx 2 seconds |
| Power Off | Press and hold the power button for approx 2 seconds |
| Play / Pause | Press the play / pause button once |
| Volume Up / Down | Press the volume up (+) / down (-) button |
| Title Next / Previous | Press and hold the volume up (+) / down (-) button for approx 1 second |
| Pick Up Call | Press the Bluetooth (phone) button once |
| End Call | Press the Bluetooth (phone) button once |
| Reject Call | Press and hold the Bluetooth (phone) button for approx 1 second |
| Turn Off Bluetooth | Press and hold the Bluetooth (phone) button for approx 2 seconds |
The Bluetooth / Battery lights on the speaker unit have different meanings.
| LED Status | Speaker Status |
| ALL off |
The battery is fully charged OR speaker is off. Total battery runtime is approx 7 hours. |
| LED flashes red |
The battery is almost empty and must be charged. |
| LED solid red |
The battery is getting charged. A full battery charging cycle is about 4 hours. |
| LED flashes blue rapidly |
The speaker is set to the Bluetooth pairing mode. |
| LED flashes blue slowly |
The speaker is properly connected to a device / plays music / connected via AUX cable. |
| LED solid blue |
The connection between the speaker and the device is setup. |
